backend dan frontend dari implementasi ontologi

Di bawah ini aku kasih versi backend dan frontend dari implementasi ontologi yang sama (library.owl) menggunakan tiga pendekatan:

1. React JS (Frontend) – Konsumsi SPARQL Endpoint

Tujuan: Fetch data dari Fuseki (localhost:3030/library/query) dan tampilkan daftar buku.

File: App.js

import React, { useEffect, useState } from 'react';

function App() {
  const [books, setBooks] = useState([]);

  useEffect(() => {
    const query = `
      PREFIX lib: <http://www.semanticweb.org/ontologies/library#>
      SELECT ?title ?author WHERE {
        ?book a lib:Book .
        ?book lib:title ?title .
        ?book lib:hasAuthor ?auth .
        ?auth lib:name ?author .
      }
    `;

    fetch("http://localhost:3030/library/query", {
      method: "POST",
      headers: {
        "Content-Type": "application/sparql-query",
        "Accept": "application/sparql-results+json"
      },
      body: query
    })
      .then(res => res.json())
      .then(data => {
        const results = data.results.bindings.map(b => ({
          title: b.title.value,
          author: b.author.value
        }));
        setBooks(results);
      });
  }, []);

  return (
    <div style={{ padding: 20 }}>
      <h1>???? Buku dan Penulis (React)</h1>
      <table border="1" cellPadding="10">
        <thead>
          <tr>
            <th>Judul</th>
            <th>Penulis</th>
          </tr>
        </thead>
        <tbody>
          {books.map((b, i) => (
            <tr key={i}>
              <td>{b.title}</td>
              <td>{b.author}</td>
            </tr>
          ))}
        </tbody>
      </table>
    </div>
  );
}

export default App;

2. PHP Backend (with CURL)

Tujuan: Query data dari ontologi dan tampilkan dalam halaman PHP.

File: index.php

<?php
$endpoint = "http://localhost:3030/library/query";
$query = <<<SPARQL
PREFIX lib: <http://www.semanticweb.org/ontologies/library#>
SELECT ?title ?author WHERE {
  ?book a lib:Book .
  ?book lib:title ?title .
  ?book lib:hasAuthor ?auth .
  ?auth lib:name ?author .
}
SPARQL;

$ch = curl_init($endpoint);
curl_setopt($ch, CURLOPT_POST, true);
curl_setopt($ch, CURLOPT_HTTPHEADER, [
  "Content-Type: application/sparql-query",
  "Accept: application/sparql-results+json"
]);
curl_setopt($ch, CURLOPT_POSTFIELDS, $query);
curl_setopt($ch, CURLOPT_RETURNTRANSFER, true);

$response = curl_exec($ch);
curl_close($ch);
$data = json_decode($response, true);
?>

<!DOCTYPE html>
<html>
<head><title>Perpustakaan</title></head>
<body>
  <h1>???? Data Buku dan Penulis (PHP)</h1>
  <table border="1" cellpadding="10">
    <tr><th>Judul</th><th>Penulis</th></tr>
    <?php foreach ($data['results']['bindings'] as $row): ?>
      <tr>
        <td><?= $row['title']['value'] ?></td>
        <td><?= $row['author']['value'] ?></td>
      </tr>
    <?php endforeach; ?>
  </table>
</body>
</html>

3. Python (Flask API)

Tujuan: Buat API REST yang ambil data dari Fuseki, lalu frontend (apa saja) bisa konsumsi.

File: app.py

from flask import Flask, jsonify
import requests

app = Flask(__name__)

@app.route("/api/books")
def get_books():
    query = """
    PREFIX lib: <http://www.semanticweb.org/ontologies/library#>
    SELECT ?title ?author WHERE {
      ?book a lib:Book .
      ?book lib:title ?title .
      ?book lib:hasAuthor ?auth .
      ?auth lib:name ?author .
    }
    """
    headers = {
        "Content-Type": "application/sparql-query",
        "Accept": "application/sparql-results+json"
    }
    response = requests.post("http://localhost:3030/library/query", data=query, headers=headers)
    results = response.json()['results']['bindings']
    books = [{"title": r['title']['value'], "author": r['author']['value']} for r in results]
    return jsonify(books)

if __name__ == "__main__":
    app.run(debug=True)

Next Steps

  • Kamu bisa gabungkan frontend React ke backend Flask atau PHP jika mau all-in-one app.

  • Untuk produksi, jangan lupa tambahkan CORS, validasi, dan pengamanan data.
